Sewage Vacuum Truck

12m³ Sewage Vacuum Truck

EMAIL

PRODUCT PROFILE

                    Product item

                    Sewage Vacuum Truck

                    HS code

                    3926909090

                    Loading capacity

                    12 m³ (customizable)

                    Overall Dimension

                    7855*2490*3425 mm

                    GVW/Kerb Weight

                     8950kg / 18000kg

                    Chassis Configuration

                    ISUZU 6H engine (240 HP)

                    ISUZU MLD six-speed gearbox
                    A/C
                    direction assist
                    central electric window control
                    6.3 front axle, 13 rear axle
                    ABS, air brake system, and 1100R20 tires
                    Bodywork Configuration                    High-quality steel tank

                    6mm thick walls

                    Ball valve water tank inlet

                     Pinfu 255L high-pressure pump (Germany), 20MPa pressure

                    SK-15 vacuum pump

                     Rear high-pressure hose coil with triangle-type double plug

                        Patterned anti-skid guardrails, galvanized protective net
                    Shock-resistant pressure gauge
                    Air-blowing function for winter operation to prevent freezing

                    Delivery time

                    35 days after receiving advance

                    Payment

                    30% by T/T in advance, and the balance 70% by T/T before shipment

                    Shipment

                    By sea, By air, By express

Features:

1. The cleaning and sewage suction vehicle integrates cleaning and suction functions, equipped with a sewage pump, tank, and pipeline system. It includes two tanks, two pumps (high-pressure cleaning and vacuum suction), and dual pipeline systems;

2. Standard Accessories:

  • User manual and maintenance guide.

  • Tool set, ball valve booster rod.

  • 60m high-pressure      pipe, 8m sewage pipe, and 10 combined nozzles.



As a pioneer of the rising Chinese manufacturing industry, Zhumadian Changchi Vehicle Technology Co., Ltd is a leading manufacturer of semi-trailers, including lowbed trailers, fuel tank trailers, container transport trailers, flatbed trailers, dump trailers, cement bulk trailers, and more.

Changchi's state-of-the-art facility covers an area of 330,000 square meters. We allocate 5% of our annual turnover to research and development, in order to continuously improve our product design and meet the special requirements and local certifications of our customers. With 21 experienced R&D colleagues and over 100 advanced manufacturing machines, we are able to maintain the highest level of product quality.

With over 20 years of production history and 10 years of overseas business experience since 2012, Changchi has exported to Southeast Asia, Australia, the Middle East, Africa, South America, and many other regions.

At Changchi, we believe that "quality is safety", and we test and examine each product thoroughly before delivery. We are committed to being the right partner for you.

Advantages and selling points:

To provide one-step service for our customer

Our offices located in Australia, Indonesia, Congo and Cambodia , giving us strength to cater the vast markets with our products and services.

Efficient service

Over 20 years’ experience of manufacturing and sales in trailer business, we can assure that the timely delivery to fit customers’ requirement.

OEM &ODM:

Our products including ordinary semi-trailer, low flat semi-trailer, half hanged container car, dumper, tank trailer, decontamination suction vehicle, concrete mixing trucks etc., which are mostly exported to Europe, America, Asia and Africa market. In the meantime, we also manufacture special products according to customer’s requirements.

Quality inspection

We carry out test on steel, welding process and completed products inspection ensure the best quality to be delivered to our customer.

About after-sales service

We have the most suitable products to meet customer’s requirements! To support the after sales service, we have professional testing machine and engineer to solve after-sales problem directly. For each products, some necessary parts, accessories will be attached to it, it makes easies customer to replace them in order to avoid any time loss.  Final but not the last, We are providing one year manufacturer warranty for any new truck or trailers against manufacture defects.
